Cigweld ShieldCor 11 1.2mm 15kg

Shield-Cor 11 is an all positional self-shielded flux cored wire recommended for the general purpose single or multi-pass lap, fillet and butt welding of mild and galvanised steels.

• 720923 – 1.2mm – 15kg
• 720925 – 1.6mm – 15kg

• Self-Shield flux cored wire
• Versatile, All positional Capabilities
• Excellent Tolerance to joint Misalignment or Poor Joint Fit-up
• Smooth Rippled filled with Good Edge Wetting
• Ideal for welding thin section mild and galvanised steels

Applications
Include the general purpose fabrication or repair of mild and galvanised steel fixtures and structures including gates, fences, steel frames, galvanised tanks and ornamental iron work etc.

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.2mm

Shield-Cor 15 is an all positional self-shielded flux cored wire recommended for single pass welding applications only. It is excellent for a single-pass lap, fillet and butt welding of thin gauged galvanised and mild steels.

Cigweld Suprecor 5 1.2mm 15kg

Supre-Cor 5 is a second generation, fully basic flux cored wire producing outstanding low-temperature impact properties using CO2, Argon or equivalent shielding gases.

• 720982 – 1.2mm – 15kg

• Second generation, fully basic flux cored wire
• Improved low-temperature impact toughness up to -50C
• Improved positional capabilities of 12mm and 16mm sizes
• DC electrode negative operation

Applications
Suitable for a wide range of critical applications including the fillet and butt welding of pressure vessels, offshore oil and gas platform structures and heavy earth moving equipment.

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.2mm

Verti-cor 111 K3 H4 is a Rutile based, low alloy flux cored wire suitable for the all positional (except vertical down) welding of high strength steels.

721381 – 1.2mm – 15kg

721382 – 1.6mm – 15kg

A high strength low alloy steel, Rutile type flux cored wire

Formulated for use with either Argon 20-25% CO2

Versatile all positional capabilities

A Nickel Molybdenum Steel Deposit of the 760 Mpa tensile class

Verti-Cor 309LT is a gas shielded stainless steel flux cored wire developed for a wide range of positional and down-hand welding applications on matching 309 and 309L stainless steels.

722881 – 1.2mm – 15kg

Verti-Cor stainless steel flux cored wires- 308LT – All positional capabilities

Vacuum sealed in aluminised plastic packs

Formulated for CO2 or Argon 20-25% CO2 Shielding gases

High deposition rate welding of stainless steel

Applications
Suitable for the dissimilar welding of other “300 series” austenitic stainless steels to mild or low alloy steels for the welding of selected “400 series” ferritic stainless steels, such as 3CR12.

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.6mm

Cigweld Verticor 3XP 1.2mm 15kg

Verti-Cor 3XP is a Grade 3 micro-alloyed Rutile type flux cored wire designed for downhand, vertical-up and overhead fillet and butt welding applications.

• 720921 – 1.6mm – 15kg

• A micro-alloyed, Rutile type fluxed cored wire
• Versatile, all positional capabilities
• Excellent operator appeal
• Formulated to give smooth(low spatter) arc transfers, flat mitre filled welds and excellent slag lift in all positions (except vertical-down), on a wide range of mild and medium strength steels

Applications
Suitable for welding a wide range of mild and medium strength steels.

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.2mm

Verti-Cor 3XP H4 is a Grade 3 seamless, rutile type FC wire designed for down-hand, vertical-up and overhead fillet and butt welding applications.

• 722919 – 1.2mm – 15kg
• Next generation technology flux cored wire
• Rutile, all positional capabilities producing a flat mixture filled bead shape
• Ultra low spatter and fume levels
• H4 diffusible hydrogen glass with a typical weld metal of 22mls of hydrogen/100gms
• Excellent operator appeal

Applications
Suitable for welding a wide range of mild to medium strength steels.

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.2mm

Cigweld Verticor 71T 1.6mm Flux Cored 15kg

VERTICOR 71T is designed for the single and multi-pass welding of mild and medium strength steels in the downhand, vertical-up and overhead positions. It is recommended for general steel construction and fabrication welding where the work cannot be rotated to the downhand positions.

Cigweld Verticor 81Ni-1 1.6mm 15kg Wire

Verti-Cor 81 Ni1 is a microalloyed, Rutile type flux cored wire suitable for the all positional welding ( flat, horizontal-vertical, vertical-up and overhead etc) of medium to high strength steels.

Packaging Data

720391 – 1.6mm – 15kg

Features & Benefits

• A higher Strength low alloy steel, Rutile type flux cored wired
• Formulated for use Argon 20-25X CO2 shielding gases
• Versatile, all positional capabilities
• Excellent operator appeal
• A normal 1% Nickel Steel deposit of the 550 MPA tensile class
• Typical applications include the under matching strength fillet welding of Bisalloy 60, 70 and 80 quenched and tempered steels

Classifications
ISO AS/NZS: 17632 B T 55 4 T1 1 M A N2 U H10
AWS/ASME-SFA A5.29: E81T1-Ni1MH8

Verti-Cor Ultra is a smooth running all positional flux cored wire which offers improved operator appeal and lower fume and spatter levels under welding grade carbon dioxide shielding gas.

Designed for the single and multi-pass welding of mild and medium strength steels in the downhand, vertical-up and overhead positions. It is recommended for general steel construction and fabrication welding where the work cannot be rotated to the downhand positions.

• 720900 – 1.2mm – 15kg

• A Rutile type flux cored wire formulated exclusively for CO2 shielding gas
• Versatile, all positional capabilities
• Excellent operator appeal
• Low spatter and fume levels

Applications
Designed for the single and multi-pass welding of mild and medium strength steels in the downhand, vertical-up and overhead positions. It is recommended for general steel construction and fabrication welding where the work cannot be rotated to the downhand positions

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.2mm

Cigweld Verticor Ultra 1.6mm Flux Cored 15kg

Verti-Cor Ultra is a smooth running all positional flux cored wire which offers improved operator appeal and lower fume and spatter levels under welding grade carbon dioxide shielding gas.

Designed for the single and multi-pass welding of mild and medium strength steels in the downhand, vertical-up and overhead positions. It is recommended for general steel construction and fabrication welding where the work cannot be rotated to the downhand positions.

• 720902 – 1.6mm – 15kg

• A Rutile type flux cored wire formulated exclusively for CO2 shielding gas
• Versatile, all positional capabilities
• Excellent operator appeal
• Low spatter and fume levels

Applications
Designed for the single and multi-pass welding of mild and medium strength steels in the downhand, vertical-up and overhead positions. It is recommended for general steel construction and fabrication welding where the work cannot be rotated to the downhand positions

Pack Type
Spool

Pack Weight
15kg = 1 Spool

Processes
FCAW

Size
1.6mm
