Cigweld Weldcraft 3.2mm 5kg Welding Electrode

Cigweld Weldcraft 3.2mm 5kg Welding Electrode

Weldcraft is a popular, rutile – basic type electrode which combines excellent all positional welding capabilities (except vertical-down) with improved radiographic weld deposit soundness and impact toughness.

Packaging Data

611203 – 3.2 mm – 5kg Pack

Features & Benefits

• Rutile – Basic Type Electrode
• Higher Radiographic Quality
• Improved Grade 2 Impact Properties
• Versatile ‘Out-Of-Position’ Capabilities

Classifications
ISO AS/NZS: 4855 B E4303 A U
AWS/ASME-SFA A5.1: E6013

Applications
Recommended for welding joints subjected to radiographic examination in pressure vessels, ship building, bridge and storage tank fabrications

Welding Positions
All Positional- except vertical down

Typical All Weld Metal Analysis
C: 0.07%
Mn: 0.60%
Si: 0.50%

Typical All Weld Metal Mechanical Properties
Yield Strength: 420 MPa
Tensile Strength: 490 MPa
Elongation: 28%
CVN Impact Values: 60J av @-20°C
